Working principle
Signal reception and conversion: The controller receives command signals from external systems, such as signals from PLC, motion controllers and other equipment, and converts them into control signals required by the motor. These control signals determine the running direction of the servo motor. Speed, position and other parameters.
Power amplification: The power amplifier amplifies the weak current signal output by the controller to provide sufficient power to drive the servo motor, so that the motor can output corresponding torque and speed to drive the load movement.
Feedback and adjustment: The servo motor's own encoder will monitor the motor's motion status, such as position, speed and other information, in real time, and send these feedback signals back to the driver. The driver compares the feedback value with the target value and adjusts the output signal according to the deviation value to ensure the accuracy and stability of the motor's movement.
Main series and features
MR-J4 series
High response speed: Using a unique high-speed servo control architecture, it achieves a cycle number response speed of 2.5kHz, which can quickly track the command signal and make the motor move faster and more accurately.
High-precision positioning: With a high-resolution position encoder, such as the 4194304p/rev encoder, high-precision position control can be achieved to meet various high-precision positioning needs.
Rich functions: It has a high degree of servo gain adjustment function. Through the automatic tuning function, mechanical resonance suppression filter, vibration control filter II, etc., it can easily suppress mechanical vibration and optimize system performance. It is also equipped with Mitsubishi servo communication network SSCNETⅢ/H, the communication speed can reach full-duplex 150Mbps, realizing high response acceleration of the system.
MR-J3 series
High-performance control: Developed on the basis of the MR-J2S series, the speed loop frequency response is increased to 900Hz, with high-speed/large torque characteristics, allowing for higher-precision control, and is suitable for occasions with high speed and precision requirements.
Multiple communication functions: With USB and RS-422 serial communication functions, it can be easily connected to the host computer. Parameter setting, trial operation, status display monitoring and gain adjustment can be carried out through a personal computer installed with servo setting software. Wait for operations.
Advanced vibration suppression function: It has high-level self-tuning function and advanced vibration suppression control function, which can effectively suppress mechanical vibration and improve the stability and reliability of the system.
MR-J2S series
Wide range of application fields: It can be used in applications that require high-precision position control and smooth speed control, such as working machinery and general industrial machinery. It can also be used in fields such as speed control and tension control.
Multiple control modes: The control modes include position control, speed control and torque control, as well as switching control methods between them, to meet different application needs.
High response performance: Using high-performance CPU, the speed loop frequency response is increased to 550Hz, which greatly improves the responsiveness of the product. At the same time, various series of servo motors adapt to different control needs. The encoders on the motors all support ABS mode, which is convenient to configure. Absolute position system.
MR-JE series: It is a series of economical servo amplifiers that provide a cost-effective option for users who have certain requirements on cost. It also has basic position control, speed control and other functions, and is suitable for some applications that do not have particularly demanding performance requirements. , but for cost-sensitive applications
MR-ES series
Multiple control modes: The control modes can be divided into MR-E-A-KH003 (position control mode and speed control mode), MR-E-AG-KH003 (analog input speed control mode and torque control mode), which can meet Control needs of different users.
Matching encoder: The encoder matching the servo motor uses an incremental position encoder with a resolution of 131072 pulses/revolution, which can provide more accurate position feedback information.
Application areas
Industrial automated production lines: widely used in transportation, assembly, handling and other links. Its high precision and rapid response characteristics can effectively improve production efficiency, reduce labor costs, and ensure the accuracy and stability of the production process.
Robotics: It is one of the core components of industrial robots and service robots. By accurately controlling the motion axis of the robot, complex operations such as welding, spraying, assembly and other tasks can be realized, allowing the robot to work according to predetermined trajectories and accuracy requirements. .
CNC machine tools: Play an important role in CNC machine tools, which can achieve precise tool feeding and cutting control, greatly improve processing accuracy and efficiency, and ensure the dimensional accuracy and surface quality of processed parts.
Packaging machinery: used to control the movement of packaging machinery, such as packaging, labeling, cartoning and other operations, which can improve packaging speed and quality and achieve automation and precision in the packaging process.
Textile machinery: used in weaving, sewing and finishing, it can improve the flexibility and efficiency of production and achieve high-quality production of textiles.
